Protection Circuit Modules [PCB] for 25.9V (7S) Li-ion Battery Pack (Working 7A, Cutoff 13A) (32171)

  • Sale
  • $35.94

Shop the Protection Circuit Modules [PCB] for 25.9V (7S) Li-ion Battery Pack (Working 7A, Cutoff 13A). Review the manufacturer description and specifications below to confirm voltage, capacity, dimensions, connector and compatibility for your application.

Special Order - Non-Cancellable - Non-Returnable - Additional Lead Time May Be Required On This Item

Product details and specifications

product highlights

Product Specifications:

Interior ResistanceMain Loop Electrify ResistanceRSS≤30mΩ
Item Content Criterion
Over Charge Protection
  • Over charge detection voltage
  • Over Charge Detection Delay Time
  • Over charge release voltage
  • 4.280±0.025V
  • 1.0±0.4s
  • 4.080±0.05V
Over Discharge Protection
  • Over discharge detection voltage
  • Over Discharge Detection Delay Time
  • Over discharge release voltage
  • Rated Operational Current
  • 3.00±0.05V
  • 144±29mS
  • 3.00±0.05V
  • ≤7A
Over Current Protection
  • Over current detection current
  • Release condition
  • Detection delay time
  • 13±2A
  • Cut load
  • 9±2mS
Short Protection
  • Detection Condition
  • Protection
  • Release condition
  • Exterior short circuit
  • Have
  • Cut short circuit
Balance
  • Balanced open voltage
  • Balanced release voltage
  • Balanced current
  • 4.200±0.035V
  • 4.200±0.05V
  • 50±5.0mA
Temperature Protection
  • Operation temperature
  • Recovery temperature
  • /
  • /
Current Consumption Current consume in normal operation 90uA Max
Dimension(L*W*H) 64.5 x 36 x 7.5 mm
