![Protection Circuit Module [PCB] for 11.1V (3S) Li-ion Battery (32048)](http://www.rocketdistributing.com/cdn/shop/files/32048_01_shopify_1024x1024.jpg?v=1789932679)
Shop the Protection Circuit Module [PCB] for 11.1V (3S) Li-ion Battery Pack (Working 3A, Cutoff 4.5A). Review the manufacturer description and specifications below to confirm voltage, capacity, dimensions, connector and compatibility for your application.
Product details and specifications
product highlights
- Apply for 3 cells Li-ion / Li-Polymer battery pack protection
- Adopts Seiko 8254 protection IC
- Adopts AO4407 MOSFET
- Apply for 3 cells Li-ion / Li-Polymer battery pack protection
- Adopts Seiko 8254 protection IC
- Adopts AO4407 MOSFET
Product Specifications:
- Overcharge protection voltage: 4.35 ± 0.05V
- Overdischarge protection voltage: 2.4 ± 0.1V
- Rated Operational current: 3A
- Overcurrent detection protection: 4.5A
- Supply current: Max 30.0uA
- Short circuit protection
- Protection ciruitry resistance: ≤70mΩ
- Dimensions: 64mm (L) x 8.9mm (W) x 2.85mm (T)
Warnings:
- Please check polarity before making connection to avoid damaging the module.
- Please make sure your selection is correct before purchasing.
- Do not forget to connect solder pad labeled "NOT USED" to the appropriate node as shown in picture. Leaving this pad disconnected will not ensure proper functioning of the PCB.
