Shop the Tenergy NiMH 18V 3800mAh Rechargeable Battery Pack (15S1P, 68.4Wh, 11A Rate). Review the manufacturer description and specifications below to confirm voltage, capacity, dimensions, connector and compatibility for your application.
Product details and specifications
Product Highlights
- ChemistryNi-MH
- Nominal Voltage (V)18
- Capacity (mAh)3800
- Max Continuous Discharge Current11A
- Weight1.9lbs
- Dimension95 x 57 x 66mm (LxWxT)
- ConnectorBare Leads
Product Highlights
- ChemistryNi-MH
- Nominal Voltage (V)18
- Capacity (mAh)3800
- Max Continuous Discharge Current11A
- Weight1.9lbs
- Dimension95 x 57 x 66mm (LxWxT)
- ConnectorBare Leads
output
- TypePack
- ChemistryNi-MH
- Cell Size4/3AF
- Nominal Voltage (V)18
- Capacity (mAh)3800
- Max Continuous Discharge Current11A
-
Battery Charging Current
- Standard0.7A
- Rapid1.8A
- Weight1.9lbs
- Dimension95 x 57 x 66mm (LxWxT)
- ConnectorBare Leads
-
Recommended Storage Temps*
- Less Than 30 Days-20 to 50°C
- Less Than 90 Days-20 to 40°C
- Less Than 1 Year-20 to 30°C
- Humidity45-85%
Supported Chargers:
| Item Number | Model/Description | Compatible Packs | Charging Current |
| 01027 | Tenergy Smart NiMH/NiCD Pack Charger for 12V-24V | 12V-24V (10-20S) | 0.5A |
| 90263 | Tenergy TB6B Multifunction Balance Charger + Power Supply | 1.2V - 18V (1-15S) | 0.1A to 5A |
*Disclaimer:
NiMH/NiCd battery voltage can drop significantly during storage due to self-discharge. We strongly recommend checking the voltage of your stored batteries, or cycle them, at least once every 6 months.
