Shop the Tenergy 24V 3800mAh NiMH Rechargeable Battery Pack (20S1P, 91.2Wh, 10A Rate, 2 Sets of Bare Leads). Review the manufacturer description and specifications below to confirm voltage, capacity, dimensions, connector and compatibility for your application.
Product details and specifications
Product Highlights
- ChemistryNi-MH
- Nominal Voltage (V)24
- Capacity (mAh)3800
- Max Continuous Discharge Current10A
- Weight2.75lbs
- Dimension125 x 69 x 50mm (LxWxT)
- Connector2 Sets of Bare Leads
Product Highlights
- ChemistryNi-MH
- Nominal Voltage (V)24
- Capacity (mAh)3800
- Max Continuous Discharge Current10A
- Weight2.75lbs
- Dimension125 x 69 x 50mm (LxWxT)
- Connector2 Sets of Bare Leads
output
- TypePack
- ChemistryNi-MH
- Cell Size4/3AF
- Nominal Voltage (V)24
- Capacity (mAh)3800
- Max Continuous Discharge Current10A
-
Battery Charging Current
- Standard0.7A
- Rapid1.8A
- Weight2.75lbs
- Dimension125 x 69 x 50mm (LxWxT)
- Connector2 Sets of Bare Leads
-
Recommended Storage Temps*
- Less Than 30 Days-20 to 50°C
- Less Than 90 Days-20 to 40°C
- Less Than 1 Year-20 to 30°C
- Humidity45-85%
Supported Chargers:
| Item Number | Model/Description | Compatible Packs | Charging Current |
| 01027 | Tenergy Smart NiMH/NiCD Pack Charger for 12V-24V | 12V-24V (10-20S) | 0.5A |
*Disclaimer:
NiMH/NiCd battery voltage can drop significantly during storage due to self-discharge. We strongly recommend checking the voltage of your stored batteries, or cycle them, at least once every 6 months.
